Ntaus Tes Ua Thiab Ti Guration Xaiv Rooj
Tus qauv | Sha 50- p} p -1 |
Tus qauv tseem ceeb | Piston + hauv nplai hluav taws xob |
Ntws ntau (m³ \/ h) | 0.002-32 |
Tso Kua Mis | Grundfos \/ Ville |
Siab Tshaj Liaj Ua Haujlwm (Bar) | 16 |
Ntev ntawm lub rooj kom raug tshuaj xyuas | DN15 (165mm), DN20 (195 hli), DN25 (225 hli), DN32 (225mm), DN50 (225mm) (qhov ntev yuav tau customized) |
Piston Speci Fi Cations | Ntim 22L, kev daws teeb meem 0. 036ml, siab PN16, Panasonic Servo Tsav |
Hluav taws xob nplai | Mettler Toledo, 1 * 60K {2}}} * 600kg |
Uas Ntim Thawv | 1*60L+1*600L |
Electromagnetic FL Towmeter | Yankawa ax.g * dn2. {5+ dn 25+1 * dn50 |
Tus sawv cev | DN25, DN50 |
Kub Sensor | PT100, Cov Chav Kawm Tau Zoo Tshaj Plaws Nruab Nrab ntawm ob qho Inlet thiab Outlet |
Siab Sensor | Qhov tseeb 0. 5% nruab rau ntawm ob qho inlet thiab qhov hluav taws xob |
Txoj kev xeem | Pib nres txoj kev \/ cov qauv ua haujlwm |
Kos Npe Interface yog cov qauv | Mem, Mbus \/ Rs485 \/ Duab Nrhiav \/ Laser Sensor |
Khoom Siv Hluav Taws Xob | 380V, 50Hz, 3 theem 5Wire Fais fab, 30KW (Peak Power) |
Lwm Hwj Chim | Dej Ntshiab \/ 6Bar Cua Siab |
Cov ntaub ntawv yooj yim
Ntaus ntawv flas | (0.002-32)m³/h |
Cuab yeej tsis muaj tseeb | Tsawg dua los yog sib npaug rau 0. 2% (k =2) |
Siab Ntau Yam | 0- 1. 6MPA |
Ib puag ncig qhov kub | 15- 25 degree |
Tus txheeb ze cov av noo | 45% -75% |
Cov Cua Siab | ({86-106}) kpa |
Ua Haujlwm Kev ntxhov siab | 0- 1. 6MPA |
Kev pab voltage | 400v ± 5% 50Hz |
Los ntshav siab | (3. {5-6) bar |
Khoom Siv Hluav Taws Xob | Lub taub dej 11Kw Piston 3KW cua sov 12kw (yeem) |
Sojector rooj ntau | DN15: 10PCS, DN20: 8pcs, DN25: 6PCS, DN35: 4pcs, DN50, DN50: 2PCS, tuaj yeem kho rau ob kab |
Qho loj dav | 5800 hli * 1500 hli * 2500 hli |
Cov kauj ruam dav dav rau kev siv lub sijhawm ntsuas dej tsis siv neeg
Tso cov ntsuas dej ntawm qhov kev ntsuas sawv ntsug thiab kho nws nrog clamps, tab sis tsis txhob ua kom npau npau. Nco ntsoov tias cov axis ntawm cov ntsuas dej yog sib dhos nrog cov yeeb nkab ntawm lub rooj ntev zaum.
Flushes cua los ntawm cov kab ke, tshem tawm huab cua npuas. Khaws cov txheej txheem siab ruaj khov. Nco ntsoov tias cov kav dej thiab ntsuas dej yog cov dej. Nruab rau cov dej me me kab rov tav lossis tig mus los tiv thaiv kom tsis txhob muaj dej xau los ntawm cov kav dej thiab dej meters.
Sau thawj zaug kev nyeem ntawm cov dej ntsuas dej.
Txog cov tshuaj ntsuam xyuas dej tshiab, pib nrog kev ntsuam xyuas siab, tom qab ntawd mus rau qhov kev ntsuas qis.
Qhib cov dej paug dej tso tawm ntawm lub rooj zaum ntsuas kev ntsuas thiab hloov kho rau qhov muaj nuj nqis ntau tshaj plaws.
Sau cov qauv hluav taws xob ntws los ntawm cov kab ke thiab cov ntim qhia los ntawm cov ntsuas dej, thiab xam qhov yuam kev.
Rov ua cov theem saum toj no rau nruab nrab ntws thiab tsawg kawg cov kev ntsuam xyuas txaus.
