Product Description
Nws yog ib qho cuab yeej ntsuas ntsuas kom tsis tu ncua ntsuas, sau tseg, thiab tso saib qhov ntim ntawm cov dej ntws los ntawm lub sensor los ntawm kev siv ultrasonic lub sij hawm sib txawv txoj kev. Thov nyeem phau ntawv no ua tib zoo ua ntej siv, siv nws kom zoo dua qub thiab zam kev tsis tsim nyog.
Daim Duab Dimension Drawing
|
Nominal txoj kab uas hla (mm) |
Ntev L |
Dav W | Siab H | Flange kev twb kev txuas | ||
| Flange Txoj kab uas hla | Bolt Circle Diameter | Bolt Loj-M | ||||
| DN 50 | 200 | 170 | 215 | 170 | 125 | 4-M16 |
| DN 65 | 200 | 185 | 220 | 185 | 145 | 4-M16 |
| DN80 ua | 225 | 200 | 235 | 200 | 160 | 8-M16 |
| DN100 | 250 | 200 | 255 | 220 | 180 | 8-M16 |
| DN125 | 250 | 250 | 285 | 250 | 210 | 8-M16 |
| DN150 | 300 | 285 | 335 | 285 | 240 | 8-M20 |
| DN200 | 350 | 340 | 405 | 340 | 295 | 12-M20 |
| DN250 | 450 | 405 | 470 | 405 | 355 | 12-M24 |
| DN 300 Nws | 500 | 460 | 525 | 460 | 410 | 12-M24 |
Interface/kev sib txuas lus
Lub ntsuas dej ultrasonic yuav muaj ib qho ntawm ntau qhov kev xaiv tso zis ua ntej xaiv thaum tso qhov kev txiav txim. Tshooj lus no yuav piav txog txhua qhov tso zis:
- Modbus / RS485 tso zis
- Pulse tso zis
- Wireless tso zis
Modbus / RS485 tso zis
Pulse Output (Battery Powered)
- Pulse tso zis parameter:
- Qhib-drain output
- Voltage 3V -24V
- Qib qis ib leeg mem tes
- Pulse Duration: 5ms
GPRS / NB-IOT wireless kis tau tus mob
Tus sau ntaub ntawv
|
Cov ntaub ntawv npe |
Parameter |
|
Lub zog ruaj khov |
15 ua |
|
Kev siv fais fab |
60 mA @ RX |
|
Tswj lub thawv |
Yas |
|
Txoj kev online |
Kov lossis txiav mus online |
|
Qhia ntu ntu |
Yuav xa cov ntaub ntawv ntau npaum li cas: ib zaug peb hnub lossis ib hnub ib zaug (Qhov siab dua qhov xa tawm, lub roj teeb lub neej luv dua) |
|
Xa me ntsis |
0.1m³ |
|
Fais fab mov |
3.6 VDC |
|
Roj teeb muaj peev xwm |
8.5ah ua |
|
Uplink interface |
GPRS/NB-IOT |
|
Downlink interface |
RS485 ua |
Data Transmission Unit
|
Cov ntaub ntawv npe |
Parameter |
|
Lub zog ruaj khov |
15 ua |
|
Kev siv fais fab |
60 mA @ RX |
|
Tswj lub thawv |
Yas |
|
Txoj kev online |
Kov lossis txiav mus online |
|
Qhia ntu ntu |
Yuav xa cov ntaub ntawv ntau npaum li cas: 1-144 h tuaj yeem teeb tsa (Default ib hnub ib zaug) tuaj yeem txuas nrog lub siab sau cov cuab yeej |
|
Xa me ntsis |
0.1m³ |
|
Fais fab mov |
3.6 VDC |
|
Roj teeb muaj peev xwm |
18Ah/36 Aw |
|
Uplink interface |
GPRS/NB-IOT |
|
Downlink interface |
RS485 ua |
