Yam khoom |
Chav tsev |
Parameter |
||||
|
Nominal txoj kab uas hla |
mm |
15 |
20 |
25 |
32 |
40 |
|
Ntev L |
258 |
299 |
345 |
305 |
330 |
|
|
Ntev L 1 |
165 |
195 |
225 |
180 |
200 |
|
|
Dav B |
95 |
95 |
95 |
95 |
95 |
|
|
Qhov siab H1 |
95 |
100 |
108 |
120 |
125 |
|
|
Overload Q4 |
m³/h |
3.125 |
5 |
7.875 |
12.5 |
20 |
|
Permanent flowQ3 |
m³/h |
2.5 |
4.0 |
6.3 |
10 |
16 |
|
Ntau yam ratioQ3/Q1 |
R=200/R250/R400(Tus qauv R yog R160), kuj tuaj yeem hloov kho. |
|||||
|
Transitional flow-rateQ2 |
m³/h |
0.02 |
0.032 |
0.05 |
0.08 |
0.128 |
|
Min flow Q1 |
m³/h |
0.0125 |
0.02 |
0.0315 |
0.05 |
0.08 |
|
Qhov tseeb |
Chav kawm 2 |
|||||
|
Chav ntsuas kub |
T30/T90 |
|||||
|
Nominal siab |
1. |
|||||
|
Siab poob chav kawm |
p63 |
|||||
|
Flow profile rhiab heev theem |
U10/D5 |
|||||
|
Climatic thiab mechanical Environmental Level |
Chav B |
|||||
|
Txoj kev teeb tsa |
Kab rov tav installation lossis ntsug installation (hauv qab dej nkag) |
|||||
Daim ntawv thov ntawm ultrasonic dej meter nyob rau hauv txawv teb
Ultrasonic Dej Meters rau Utilities
Adaptive deployment - ua raws li cov kev cai ntawm cov tuam txhab siv hluav taws xob pej xeem cov ntsuas dej, ua raws li cov qauv hauv tebchaws, thiab tuaj yeem koom nrog cov phiaj xwm kev sib tw
Tau tshaj Smart Water Management Solutions - tuaj yeem ua ke nrog kev ntsuas ntsuas software rau AMI Smart Water Management daws teeb meem.
Ultrasonic Dej Meters rau cov ntawv thov nyob
Txhim khu kev ua haujlwm - Muab ib qho yooj yim-rau-nyeem LCD zaub qhia kev siv, ntws, rov qab ntws cov ntaub ntawv thiab ceeb toom.
Long Term Accuracy-Tau qhov tseeb mus sij hawm ntev nyob rau hauv qhov ntxiv 1.5 feem pua ntau thiab txuas ntxiv qhov tsis txaus txaus hauv qhov ntxiv 3 feem pua.
Tau tshaj Smart Water Management Solutions - Ua ke nrog kev ntsuas ntsuas software suites rau AMI lossis AMR ntse dej tswj kev daws teeb meem.
Ultrasonic dej ntsuas rau kev lag luam daim ntaub ntawv
Cov Ntaub Ntawv Siab thiab Tswb-Lub tswb nrov thiab cov ntaub ntawv ceeb toom ntawm cov ntaub ntawv siab thiab kub muaj nyob rau hauv Kev Ntsuas Ntsuas Qhov Ntsuas.
Txhim kho Gauge Display - Muab cov ntaub ntawv nkag tau zoo dua thiab pom kev hauv qhov ntsuas.
Qhov dav dav dav dav - Muab ntau dua turndown ratios rau wider flow ranges, ua rau cov nyiaj tau los ntau dua.
