Hebei Shanghong Meters Technology Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm sts ultrasonic tooj dag dej ntsuas sh5170 hauv Suav teb. Yog hais tias koj yuav mus lag luam wholesale zoo sts ultrasonic tooj dag dej meter sh5170, txais tos kom tau pricelist thiab hais los ntawm peb lub hoobkas.
STS Ultrasonic Dej ntsuas dej piav qhia
CovSTS ultrasonic dej ntsuasyog siab -precision electronic prepaid water meter. Nws txais yuav lub sij hawm ultrasonic- txawv txoj hauv kev los ntsuas tsis tu ncua, sau tseg, thiab tso saib qhov ntim dej dhau los ntawm lub sensor.
Nws ua tau raws li cov kev cai nruj ntawm cov khoom siv dej rau kev ntsuas dej kom raug. CovSTS ultrasonic dej ntsuasyog sib xws nrog IoT kis tau tus mob thev naus laus zis, ua rau cov tub ceev xwm dej nkag mus rau ntau yam kev daws teeb meem. Nws yog dav siv hauv prepaid water metering rau tsev neeg, tsev, thiab chaw lag luam.
STS ultrasonic dej ntsuas nta
- Ultrasonic STS dej ntsuas tsis muaj qhov txav mus rau sab hauv, kom tsis txhob hnav thiab tswj xyuas qhov tseeb thoob plaws hauv nws lub neej kev pabcuam.
- Lub ntsuas dej txhawb nqa 9 tus lej LCD, nrog qhov ntsuas qhov tsawg kawg nkaus ntawm milliliters (mL).
- Ultrasonic STS dej ntsuasua raws li cov kev cai ua haujlwm ntawm STS raws tu qauv (IEC-62051).
- Nws tso cai rau cov cuab yeej siv los xa cov lus txib encrypted rau lub ntsuas, nrog kev sib txuas lus siab tshaj plaws ntawm 300 meters.
- Lub ntsuas dej txhawb nqa ntsug, kab rov tav, lossis inclined installation txoj haujlwm thiab tau nruab nrog kev tiv thaiv -tampering functions.
- Nws txhawb kev rov qab khiav kom paub tseeb.
- STS ultrasonic dej ntsuas kuj txhawb nqa cov yeeb nkab khoob khoob.
- Nrog IP68 tiv thaiv kev ntsuas, nws tsim nyog rau ntau yam kev teeb tsa hnyav.
STS ultrasonic dej ntsuas tsis
|
Nominal Dia
|
mm
|
15 | 20 | 25 | |||
|
Q3/Q1
|
R250 / R400 (yeem)
|
||||||
|
Overload Flow tus nqi (Q4)
|
m³/h
|
3.125 | 5 | 7.875 | |||
|
Nominal Flow Rate (Q3)
|
m³/h | 2.5 | 4 | 6.3 | |||
|
Transitional Flow Rate (Q2)
|
l/h
|
16 | 10 | 25.6 | 16 | 40.32 | 25.2 |
|
Tus nqi qis qis (Q1)
|
l/h
|
10 | 6.25 | 16 | 10 | 25.2 | 15.57 |
|
Cov chav kawm siab poob
|
l
|
△P40
|
△P40
|
△P25
|
|||
|
Chav Kawm Kub
|
T30/T50
|
||||||
|
Maximum Admissible Siab
|
PN16 (232 psi)
|
||||||
|
Electromagnetic Environmental Class
|
E1 | ||||||
|
Chav kawm tiv thaiv
|
IP68 | ||||||
|
Kev taw qhia Installation
|
Txhua lub kaum sab xis thiab txoj haujlwm
|
||||||
|
Flow Profile Sensitivity Class
|
U5/D3
|
||||||
|
Lub neej roj teeb
|
Ntau dua lossis sib npaug li 6 xyoo
|
||||||
STS ultrasonic dej ntsuas kev sib txuas lus txoj kev
